SC-6200M System

Your Professional SC-6200M System Supplier


Guangzhou SONBS Electronic Technology Co., Ltd was established in 2006, located in Panyu district of Guangzhou. SONBS is the trustworthy integrated supplier of audiovisual systems, integrating R&D, production, sales and service together in China for more than 19 years.




First 12 Last

Why Choose Us

Professional Team

We have 50 R&D engineers, 100 pre-sales and after-sales technicians, 250 sales and 200 assembling workers, all totally about about 600 employees.

Provide Technical Training

Our professional engineer team can offer technical training and guide the customer to install equipment, for big project, we can send engineer on site to guide the installation.

Advanced Equipment

Yamaha YV100Xe SMT Mounter, Hitachi GXH-3 SMT Mounter, Optical Inspection Instrument, Printer, Programmable Thermostats, Ground Tester,High Voltage Tester, Digital Oscilloscope, Audio Signal Generator, Voltmeter, Millivoltmeter, Voltage regulator, Capacitance Leakage Tester,Transistor DC Tester, Frequency Sweeper, Vernier calipers etc.

Certification

All product lines have passed the mandatory Product Certification (3C Certification) and have passed ISO9001 Quality Certification, ISO14001 Environmental certification, and ISO18001 Occupational Health certification.The plant has passed the SGS and Alibaba onsite certification.





SC-6200M System Specifications



Type

Wired Digital Chairman Conference Unit

Functions

Speech, Sign-in, Voting, Camera Tracking, Gain/EQ/AGC adjustable.

Display

4-inch full-color capacitive touch screen

Screen Resolution

480×480 (RGB)

Screen Refresh Rate

60Hz

CPU

Dual-core 1.0GHz processor

Memory

256M SPI Flash

Speech Management

Chairman can approve/deny representatives’ speech, see queue list

Microphone Type

9.7mm gold-plated electret condenser, cardioid

Pickup Distance

50 cm

Audio Encoding

MP3 / PCM / ADPCM

Sampling Rate / Bitrate

8kHz–48kHz, 16bit, 8Kbps–320Kbps

SNR / Frequency Response

≥83dB, 40Hz–18kHz

Mic Frequency Response

20Hz–20kHz

Mic Sensitivity

-41dB ±2dB (0dB=1V/Pa at 1kHz)

Max SPL

120dB SPL, 1kHz at 1% T.H.D

Indicator Lights

Speech status light on mic rod (red when active); base connection status light

Connection Ports

Dual RJ45 network ports; daisy-chain connection

Connection Cable

Cat6 network cable

Headphone Output

φ3.5mm stereo jack

Signal Transmission

Full digital, strong anti-interference

Power Supply

24V centralized power from host unit

Power Consumption

≤3.5W

Panel Material

Aluminum alloy, sandblasted & electroplated

Base Material

ABS

Operating Temp/Humidity

0–45℃, ≤90% RH (non-condensing)



productcate-730-730



Features

The microphone panel is made of aluminum alloy with dual process treatment, brushed with matte sandblasted black, beautiful and elegant, durable.



The microphone uses a 1.5V dry battery, which can be easily replaced at any time. The microphone automatically shuts down when the host is turned off; *The microphone is designed with high-strength anti mobile electromagnetic wave interference, which can eliminate mobile phone interference noise and suppress adjacent frequency interference.



The chairman's microphone has a priority function, which can turn off all active representative microphones with one click.



The microphone switch uses automotive grade rubber switch buttons, which are durable and have a slight mechanical sound characteristic.





Type

Analog conference system

Signal is transmitted with the analog form. Due to the functional limitations of analog signals, this type of conference system is limited in terms of integration and additional functions despite its moderate price.

Omnidirectional Microphones

It is suitable for receiving all sounds in a space. However, it also means that it will receive background noises. If there is loud wind noise or cooling system, the sound reception quality will be affected.

Digital conference system

The built-in digital signal processing (DSP) chip offers clear audio quality. It features a wide range of functions and unlimited possibilities for integration. It is the mainstream of the current conference microphone system.

Directional Microphones

This microphone has a pick-up pattern that mainly captures the sound from the front, and rejects the sound from the rear. When a sound signal is amplified, or in a space with poor acoustics, the sound can be picked-up clearly.



Applications





Voting and parliamentary procedure functions

For Example, voting processes, tracking historical votes, secret ballots, etc.



Record, lecture capture and live-streaming

More and more technologies integrate with conference microphone system.



Video conferencing

Video Conferencing is the trend and more popular than ever – a conference microphone system can be integrated with the PTZ camera and cloud video conferencing software.





Our Certificates



productcate-1-1



FAQ



Q: Are you a manufacturer or a trading company?

A: Yes, we have our own factory with over 10 years of research and manufacturing experience.

Q: Do you have any certifications?

A: Yes, we have CCC, CE, and RoHS certifications.

Q: Can you produce products according to our requirements?

A: Of course, we can design the desired items according to your needs. We have extensive experience in OEM/ODM.

Q: How can I obtain a sample if I need one?

A: If you require a test sample, we can arrange it according to your specifications. You will need to cover the sample cost and shipping fees, which we will refund once you place a formal order.

Q: What is the quality of your products like?

A: We inspect and test each product individually before shipment to ensure 100% quality.

As one of the most professional sc-6200m system manufacturers in China, we're featured by quality products and good service. Please rest assured to buy customized sc-6200m system at competitive price from our factory.
