Features
1.2.23-inch OLED screen with a simple and intuitive UI design.
2.Supports three microphone output modes: FIFO, Normal Mode, and Voice-Activated.
3.Chairman unit includes a priority button to mute active delegate microphones.
4.Utilizes the TCP/IP protocol for stable, long-distance transmission with high-quality sound.
5.Supports up to 6 microphones simultaneously with stable output and no interference.
6.Includes a 5-band EQ adjustment, allowing customization of microphone sensitivity and transmission channels.
7.Equipped with a knob-type plug-in microphone featuring a dual-color indicator.
8.Integrated headphone jack and volume adjustment buttons for user convenience.
9.Handrail-link microphone transmission with dual network ports.
10.External Type-C port for easy upgrades and disassembly.
11.Built-in speech timing function.
12.Six multi-function buttons supporting voting, volume control, and mode switching.
Technical parameters
|
Microphone Type |
Electret Condenser Microphones |
|
Microphone Directivity |
Unidirectional Cardioid |
|
Frequency Response |
60Hz~18KHz |
|
Microphone Input Impedance |
1KΩ |
|
Sensitivity |
-43±1dBv/Pa |
|
Maximum SPL |
120dB(THD>3%) |
|
Signal-to-noise ratio |
>80dB(A) |
|
Crosstalk |
>70dB |
|
Dynamic Range |
>80dB |
|
THD |
<0.3% |
|
Max Power Consumption |
2W |
|
Power supply method |
Conference host power supply 36V |
|
Colour |
Black colour |
|
Chassis Dimensions (mm) |
285L*122W*45H |
|
Mounting Method |
Embedded |
|
Weight (LxWxH) |
0.94kg |
|
Microphone Length |
412*25*25mm |
