Description
The SD-12M is a professional stage monitor speaker meticulously designed to deliver pristine audio reproduction for performers. It combines a powerful, authoritative presence with exceptional sonic clarity, ensuring every vocal nuance and instrument detail is heard with absolute fidelity. Its wide, smooth frequency response provides consistent coverage, making it the trusted choice for demanding stage monitoring applications in live sound, as well as premium installations in high-end entertainment venues, clubs, multi-function halls, auditoriums, and theaters.
Features
* Superior Vocal Clarity & Accurate Reproduction: Specifically tuned to provide crystal-clear mid-range and vocal projection, ensuring performers hear themselves perfectly on stage.
* Wide & Smooth Frequency Response: Delivers a balanced and natural sound across the entire spectrum for reliable and honest monitoring.
* High-Power Handling & Output: Robust 400W AES power rating (1000W peak) ensures ample volume and headroom for even the most dynamic performances.
* Exceptional Sensitivity & High Maximum SPL: 98dB sensitivity and 128dB peak SPL provide high output efficiency and powerful sound projection with minimal amplifier strain.
* Controlled 60° x 90° Dispersion: Offers optimal coverage area on stage, reducing unwanted spill and feedback while ensuring consistent sound for performers.
* Durable & Road-Ready Construction: Features a rugged 18mm plywood cabinet with a textured black paint finish, built to withstand the rigors of touring and frequent use.
* Versatile Application: The ideal monitor solution for live stages, and also excels as a compact, high-quality main or fill speaker for fixed installations in various entertainment and professional audio environments.
Key Advantages
* Exceptional Sound Accuracy: 45Hz-20KHz wide frequency response, delivering clear and full vocals with perfectly reproduced instrument details.
* Powerful Performance: 400W-500W continuous power, 1600W-2000W peak power, and 127dB-131dB max SPL for room-filling sound.
* Precise Dispersion: 90° horizontal + 60° vertical coverage ensures even sound distribution, eliminating dead zones for stage monitoring.
* Professional Build: 12" & 15" woofers + 44mm titanium diaphragm tweeters, 18mm birch plywood cabinet-durability meets premium acoustics.
* Versatile Application: Ideal for theaters, livehouses, multi-purpose halls-lightweight and easy to transport.
Technical parameters
|
Type |
TFront-conducting phase type |
|
Speaker unit |
LF 1*12" ferrite/voice coil ∅65mm/magnet ∅170mm HF 1*1.73" ferrite compression tweeter/voice coil ∅44mm |
|
Rated power (AES) |
8Ω |
|
Rated power (AES) |
400W |
|
Peak power (AES) |
1000W |
|
Frequency response (±3dB) |
55Hz-18KHz |
|
Sensitivity (1m/1W) |
98dB |
|
Directivity (H *V) |
60°*90° |
|
Maximum sound pressure level (1m/1W) |
128dB (peak) |
|
Surface treatment |
black spot paint |
|
Size |
580×415×316mm |
|
Weight |
22kg |
