Product Features
- The product adopts the most advanced H.265 network high-definition digital audio and video chip compression technology, with stable and reliable, high-definition, low bit rate, low latency and other technical characteristics;
- The product input is HDMI video signal, after the main chip video compression encoding processing, the standard video stream of various protocols is output through the network.
- The use of embedded operating system ensures that the product is more stable.
- The industrial-grade aluminum alloy shell design is adopted, which is small in size and easy to install.
Technical parameters
|
Encoding type |
H.264/H.265 optional |
|
Support resolution |
1920*1200@60/1080P60 and other conventional resolutions |
|
Embedded WEB service |
support IE browsing, configuration, upgrade |
|
Video input |
1 HDMI |
|
Audio input |
1 HDMI built-in audio, 1 HDMI external audio |
|
Video output |
1 HDMI |
|
Audio output |
1 HDMI built-in audio |
|
Audio sampling rate |
44100/48000 Optional |
|
Encoding frame rate |
5-60 adjustable |
|
Key frame interval |
5-300 adjustable |
|
Bit rate |
32-32000 adjustable |
|
Transmission protocol |
support RTMP/RTSP/HTTP TS/HTTP FLV/HLS/UDP multicast/RTP multicast |
|
Power |
<5w |
|
Dimensions (width × depth × height) |
150mm x 100mm x 32mm |
|
Network interface |
RJ45-10M/100M/1000M adaptive Gigabit network port |
|
Working temperature |
-20℃+60℃ |
|
Working humidity |
<90%, no condensation |
|
Power interface |
12V/DC, 2A |
|
Weight |
0.3Kg |
