Technical parameters
|
Model |
SA-356R |
SA-358R |
|
Frequency response |
80Hz~20KHz(±3dB) |
70Hz~20KHz(±3dB) |
|
Number of units |
LF:1x6.5"(1"voice coil),HF:1x1"(1"voice coil) |
LF:1x8"(1"voice coil),HF:1x1"(1"voice coil) |
|
Nominal impedance |
8 ohms |
8 ohms |
|
Withstand power |
60W |
100W |
|
Maximum power |
120W into 8ohms |
200W into 8ohms |
|
Directivity |
90°Hx90°V |
90°Hx90°V |
|
Maximum sound pressure level |
113dB/1m |
116dB/1m |
|
Sensitivity |
95dB |
96dB |
|
Box body plate |
ABS steel back cover |
ABS steel back cover |
|
Connection socket |
Two spring sockets |
Two spring sockets |
|
Size |
Φ265x223mm |
Φ280x260mm |
|
Mounting hole size |
Φ223mm |
Φ245mm |
|
Net weight |
5kg (1pcs) |
6kg (1pcs) |
