Features:
- The 4.3-inch TFT color display enables real-time monitoring of 8 channels, showing channel numbers, volume levels, operating frequencies, RF power, and audio waveforms. All settings can be easily adjusted via the responsive touch screen interface.
- Featuring true diversity reception technology, the receiver's intelligent CPU automatically selects the optimal antenna signal to ensure stable reception and prevent signal dropouts.
- A display lock function prevents accidental adjustments-once activated, channel and volume settings remain fixed to avoid unintended changes during operation.
- Equipped with a built-in feedback suppressor, the receiver allows users to enable or disable this function as needed to eliminate microphone howling.
- With a dedicated one-touch mute button, the system can instantly silence all 8 channels simultaneously for quick audio control.
- The receiver includes multiple preset frequency groups designed to avoid interference, significantly improving setup efficiency when operating multiple systems together.
- Four EQ modes are provided, including a customizable user mode that allows flexible adjustment of an 11-band equalizer for tailored sound in various acoustic environments.
- It offers extensive connectivity options: 8 antenna interfaces, 2 mixed unbalanced outputs, 2 mixed balanced outputs, and 8 balanced independent outputs.
- The host unit also features a one-touch mute function, capable of instantly muting all 8 channels at once.
- A host display lock function secures system settings-once engaged, channel and volume adjustments are disabled to prevent accidental changes.
- The microphone unit supports adjustable transmission power (high/low modes), allowing users to optimize battery life based on actual usage needs.
- The compact speaker unit includes a configurable auto-shutdown timer (1–8 hours). Once set, it automatically powers down during periods of inactivity, extending both battery life and overall product durability.
Technical parameters:
|
Receiver technical parameters |
|
|
Working frequency |
640-690MHz |
|
Modulation Mode |
Broadband FM |
|
Channel |
200 channels |
|
Bandwidth |
50MHz |
|
Sensitivity |
-95dBm |
|
Frequency stability |
±0.001% |
|
Dynamic range |
>90dB |
|
Peak frequency deviation |
±45KHz |
|
Frequency response |
50Hz-18KHz (±3dB) |
|
Comprehensive signal-to-noise ratio |
>85dB |
|
Comprehensive distortion |
<0.5% |
|
Usage distance |
50-80 meters |
|
Frequency matching method |
infrared + wireless |
|
Audio output |
Mixed: 0-600mV, balanced: 0-600mV |
|
Working power |
DC12V/2A |
|
Power consumption |
12W |
|
Dimensions |
480*250*85mm |
|
Weight |
3.4KG |
|
Technical parameters of conference unit |
|
|
Channel |
200 channels |
|
2.8-inch TFT color display |
displays transmission frequency, channel, battery power, speech timing |
|
Transmitting power |
10mW |
|
Spurious suppression |
-60dB |
|
Harmonic suppression |
>55dBc |
|
Power supply voltage |
3.6V/ 3000mAh lithium battery |
|
Working time |
speaking mode>18 hours, standby mode>20 hours |
|
Weight |
0.87KG |
|
Base size |
(W*L*H)95*135*55mm |
|
Square tube microphone rod |
230mm |
